Solid Core End Glow

  • 11mm End Light Cable
  • 11mm End Light Cable
  • 11mm End Light Cable
11mm End Light Cable11mm End Light Cable11mm End Light Cable

11mm End Light Cable

  • Core Material: PMMA
  • Core Diameter:8mm
  • Cable Diamter:11mm
  • Sheath Material: Transparent PVC
  • Product description: 11mm end light solid core fiber optic cable consists of one large 8mm PMMA polymer fiber core surrounded by a UV stablized protective PE or PVC sheathing for mechanical protection. Mainly used for fib
  • INQUIRY

PMMA Fiber Optic, also known as Plastic optical fiber (POF) ,Polymer Optical Fibre, is an optical fiber that is made of polymer. Similar to glass optical fiber, POF transmits light (for fiber optic lighting or data transmission) through the fiber core. Compared with traditional fiber optics , PMMA fiber optic has better bending radius and stretching.

Our solid core end light fiber and cable consists of one large PMMA polymer fiber core jacketed by a UV stablized protective transparent PVC sheathing for mechanical protection. Mainly used for starry ceiling lighting, pool starry lighting, stage lighting, holiday lighting.

Solid Core End Light Fiber Optic Characteristics:

1. Safe, transmit light only, no conductivity or heat transferring;

2. Being able to transmit visible light but not ultraviolet or infrared;

3. Unique loose jacket adopted in the lighting series , easy to peel off,install and maintenance;

4. Good flexibility,stable performance, anti-aging, long life span;

5. Strongest light effect at the end of the fiber;

6. Operating temperature: -20 ~ +70

7. Allowable bending radius:≥ ten times of the fiber diameter;

Solid Core End Light Fiber Optic Applications:

The fiber optic solid core end glow cables are mainly used for starry ceiling lighting, pool starry lighting, stage lighting, holiday lighting.

Solid Core End Light Fiber Optic Ordering Information:

P/N

Cable Diameter

(mm)

Fiber Diameter

(mm)

Packing

Carton Size

(mm)

Sheath Material

GET-2

3.5

2

carton

500x500x300

Black PE

GET-2.5

4

2.5

carton

500x500x300

Black PE

GET-3

4.5

3

carton

500x500x300

Black PE

GET-6

8.8

6

carton

500x500x300

Black PE

GET-8

11

8

carton

500x500x300

Black PE

GET-10

13

10

carton

500x500x300

Black PE

GET-11

14

11

carton

500x500x300

Black PE

GET-12

14

12

carton

500x500x300

Black PE

GET-14

17.3

14

carton

500x500x300

Black PE

GET-16

18

16

carton

500x500x300

Black PE

GET-18

20

18

carton

500x500x300

Black PE
